Bow Cabler
The bow cabler uses a series of synchronously rotating bows arranged in a straight line to twist conductors into cable cores. Through the synchronized rotation of multiple bows, it forms uniform cable cores while maintaining stable conductor handling throughout the process. It is commonly used for the production of control cables, power cables, and other multi-core cable constructions.
Technical Specifications
| Model | Maximum Rotational Speed (rpm) | Max. Core Diameter (mm) | Max. Loading Capacity (kg) | ||||
| 2B | 3B | 4B | 5B | 6B | |||
| 800 | ⌀10 | 700 | |||||
| 450 | 450 | 450 | 450 | 450 | ⌀16 | 1000 | |
| 360 | 360 | 360 | 360 | 360 | ⌀20 | 2500 | |
| 300 | 300 | 300 | 300 | 300 | ⌀25 | 4500 | |
Deyang XDG is dedicated to the design and manufacture of cable and wire machinery, from metal rod continuous casting and rolling to wire drawing, stranding, cabling and extrusion. Beyond supplying wire and cable production equipment, we specialize in providing complete solutions to help global wire and cable manufacturers improve production efficiency and reliability. Our equipment including CCR lines, wire drawing machines, stranding machines, cabling machines as well as auxiliary equipment such as take-up units and cable packing machine is widely utilized in the production of power transmission cables, electrical conductors, communication cables, photovoltaic cables, and more.
